With a slim form factor and only 2.2 kg weight, this pack provides 252 Wh of safe, maintenance-free power. Perfect for portable medical pumps, handheld diagnostic tools, and field-service UPS units.
Flexible Customization & Quality Guarantee
Himax’s factory offers tailored cable lengths, connector types (Anderson, Molex), and optional LCD status display. Every battery is cycle-tested and quality-inspected, with full traceability and 18-month warranty.
Specifications
Customization LiFePO4 Battery 25.2V 10Ah
Nominal Voltage
25.2V
Nominal Capacity
10Ah
Energy
252Wh
Charge Voltage
252Wh
Discharge cut-off voltage
18.9V
Charge Method
CC/CV
Standard Charge Current
2A
Max. Charge Current
5A
Standard Discharge Current
2A
Max. Continues Discharge current
5A
Cycle Life
2000 times
Dimension
161*60*76mm
Weight
Approx 1600g
Storage Temperature
-10°C~45°C
Frequently Asked Questions
Himax Battery specializes in providing class A LiFePO4 batteries for bulk buyers, offering flexible customization options to meet your specific requirements. Our wholesale solutions ensure high-quality, cost-effective batteries for large-scale applications.
1. Can this pack serve as a 25.2V hoverboard battery replacement?
Yes—its 25.2V (8S) LiFePO₄ design matches standard hoverboard specs and improves safety and cycle life over OEM cells.
2. Is this compatible with a 24v power supply or charger?
It charges on any 24V lithium ion battery charger suited for 25.2V nominal packs—Himax can supply matched charging units if needed.
3. Can I use this with a 24v trolling motor?
Definitely. Its lightweight design and 10Ah capacity provide efficient, long-lasting power for low-draw 24V trolling motors on small watercraft.
4. What makes this 24v lithium ion battery safe for medical devices?
LiFePO₄ chemistry offers exceptional thermal stability and low self-discharge. Each pack undergoes multiple safety tests, including short-circuit and over-charge protection.
5. Do you offer custom cable and connector options for integration?
Himax’s factory supports customization of cable lengths, discharge connectors (Anderson, Molex), and optional status displays to fit any portable electronics setup.
