7.26V 5000mAh 21700 Lithium-Ion Battery Pack with UL2595 BMS for Safe Charging

Lithium ion Battery about Medical, Outdoor Sports | Rechargeable, High capacity

Categories 7.4V Lithium Ion Battery, Lithium lon Battery

Nominal Voltage
7.26V

Nominal Capacity
5000mAh

Energy
36.3Wh

Stay powered on the go with this 7.26V 5000mAh 21700 lithium-ion battery. Equipped with a UL2595 BMS, it offers safe charging for medical devices and outdoor sports gear. Its high-capacity design ensures long runtime, while the rechargeable feature keeps you ready for action, anytime, anywhere.

INQUIRY TO BUY

Description
Specifications
FAQs
Download

Lithium-ion Battery Pack

Lithium Battery 7.26V 5000mAh

High‑Energy Density & Tailored Performance

Samsung INR21700‑50G cells in a 2S1P configuration offer 5000 mAh capacity and up to 5 A continuous output—Himax’s engineers will optimize discharge curves for your device’s power profile.

Robust Protection & Custom Integration

UL2595 dual‑circuit BMS with built‑in temperature control switch guarantees safe operation—and Himax provides custom wiring harnesses, connector styles, and firmware settings to suit your system.

Specifications

Samsung INR21700 Lithium Battery Pack 7.26V 5000mAh

Nominal Voltage

7.26V

Nominal Capacity

5000mAh

Energy

36.3Wh

Charge Voltage

8.4V

Discharge cut-off voltage

5.5V

Charge Method

CC/CV

Standard Charge Current

Max. Charge Current

2.5A

Standard Discharge Current

Max. Continues Discharge current

Cycle Life

300 times

Dimension

24.5*44.5*73.5mm

Weight

Approx 160g

Storage Temperature

-10°C~45°C

Frequently Asked Questions

Lithium ion battery pack answers, if you do not find the answer you are looking for, please contact us. We’ll get back to you within 24 hours.

1. What is the maximum charge and discharge current?

Standard charge current is 2 A (CC/CV to 8.4 V), with 5 A maximum continuous discharge. Custom charge rates up to 3 A can be defined.

2. How compact is the pack, and can dimensions be adjusted?

The pack measures 24.5 × 44.5 × 73.5 mm. Himax can tailor pack dimensions or cell arrangement for tight‑fit applications.

3. What protection features are included in the UL2595 BMS?

Dual‑circuit over‑charge/discharge protection, over‑current trip, short‑circuit shutdown, and an onboard temperature switch.

4. Can I get custom wiring harnesses and connector types?

Yes—standard is 20 AWG UL3239 leads (50 ± 5 mm). Himax can fit Molex, JST, VH, or any OEM connector and adjust lead length per spec.

5. What is the minimum order quantity (MOQ) for customization?

The standard MOQ for custom-branded or modified packs is 50 units. For stock‑configuration orders, MOQ is 10 units.

Download

Didn’t find the battery you were looking for or need a customized battery please contact us.

#Download Lithium ion battery 7.26V 5000mAh specifications
