Ensure safety with this 14.8V 2Ah high-discharge (5C) lithium-ion pack. Its 4S1P 18650 2000mAh cells with JST-XHP-7P connector power emergency lighting, medical, and security devices. Wrapped in green PVC, this rechargeable battery offers reliable, high-capacity performance for critical applications.
Engineered with 5C-rated 18650 2000 mAh lithium-ion cells for peak power delivery up to 10 A, this pack sustains high-drain applications—ideal for portable tools and UAVs. Himax’s custom BMS tuning ensures balanced cell management and real-time current monitoring.
Tailored Connector & Housing Options
Himax offers bespoke configurations: choose JST-XHP-7P polarity, cable length, and a choice of green PVC or clear shrink wrap. Perfectly sized (70 × 74 × 20 mm) and individually bagged for streamlined assembly.
Specifications
14.8V 2000mAh Lithium ion battery pack
Nominal Voltage
14.8V
Nominal Capacity
2000mAh
Energy
29.6Wh
Charge Voltage
16.8V
Discharge cut-off voltage
11V
Charge Method
CC/CV
Standard Charge Current
0.4A
Max. Charge Current
1A
Standard Discharge Current
0.2A
Max. Continues Discharge current
10A
Cycle Life
500 times
Dimension
70*74*20mm
Weight
220g
Storage Temperature
-10°C~45°C
Frequently Asked Questions
Lithium ion battery pack answers, if you do not find the answer you are looking for, please contact us.
We’ll get back to you within 24 hours.
1. What is the maximum continuous discharge current of this 14.8V 2Ah Li-ion power pack?
Thanks to its 5C-rated 18650 cells, this pack delivers up to 10 A continuous discharge, perfect for high-drain devices and portable power tools.
2. How long does the 14.8V 2000 mAh battery pack run under a 5 A load?
With a 2 Ah capacity, you can expect approximately 24 minutes of runtime at a 5 A draw (2 Ah ÷ 5 A = 0.4 h).
3. Can I customize the connector or cable length on this 4S1P battery module?
Yes—Himax offers bespoke JST-XHP-7P polarity, cable lengths, and PVC sleeve colors to match your exact build requirements.
4. Is the pack protected against over-charge and over-discharge?
Absolutely. Himax’s integrated BMS monitors voltage and current in real time, cutting off at programmable thresholds to safeguard cell health.
5. How should I store the 14.8V 2Ah lithium-ion battery for long periods?
Store at 40–60% state of charge, in a cool, dry place (15–25 °C). Recharge to 50% every three months to maintain cycle life.
